Min. Ordni:1 Piece/Pieces
Brand: Risingstar
Produttività: 135K
Post ta 'Oriġini: Shenzhen
Ċertifikat: CE/ROSH/UL/ISO9001
15.4inch 1000 Nits Outdoor TFT LCD Screen minn Shenzhen Risingstar. Dan il-modulu LCD 15.4 "bit-teknoloġija A-SI TFT-LCD, mgħammra bil-backlight WLED, inkluż is-sewwieq tal-backlight drive.With Sensor tad-dawl, il-luminożità tista 'tiġi aġġustata skont id-dawl viċin tad-dawl viċin Is-sorsi jinbidlu.
L-iskrins LCD ta 'luminożità għolja għandhom bżonn sigħat twal ta' xogħol, u d-diversità tal-ambjent u l-bidliet fit-temperatura huma kbar. Għalhekk, kuntrast għoli, durabilità u stabbiltà saru karatteristika indispensabbli ta 'skrins LCD industrijali. 15.4 pulzier TFT LCD Panel jissodisfaw dan il-ħtiġijiet.
Il-luminożità ordinarja tal-luminożità tal-pannell LCD tista 'tilħaq biss 350Nits, iżda l-15.4inch 1000 NITs TFT LCD Screen LCD L-Iskrin Għoli jista' jinkiseb 1000 CD / m 2 , 1000NITS L-iskrin tal-luminożità għolja huwa użat ħafna fil-kabinetti espressi, Elettroniku Bus Stop Reklamar Screen , Aqra fil-beraħ il-kolonna tal-gazzetta, il-kolonna tal-pubbliċità taż-żona xenika, eċċ.
| Product size | 15.4" | Type | a-Si TFT-LCD |
| Pixel Format | 1920(RGB)×1200[WUXGA] 147PPI | Configuration | RGB Vertical Stripe |
| Active Area | 330.62(H)×206.64(V) mm | Outline Dim. | 341.2(H)×219.14(V) ×13(D) mm |
| Viewing Angle | 80/80/70/70 (Min.)(CR≥10) | Treatment | Hard coating (3H) |
| Luminance | 800-1000 cd/m² (Typ.) | Contrast Ratio | 1450:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 10/8(Typ.)(Tr/Td) |
| Support Color | 16.2M 56% NTSC | Light Source | WLED ,20K hours , With LED Driver |
| Weight | 830/850g(Typ./Max) | Designed For | Outdoor High Brightness Automotive Display |
| Frequency | 60Hz | Touch Panel | Without |
| Interface Type | LVDS(1 ch,2 port) , 6pins | ||
| Power Supply | 12.0V (Typ.) | ||
| Environment | Operating Temperature: -40 ~ 95 °C ; Storage Temperature: -30 ~ 85 °C |
