Mudell Nru.: EV101WXM-N81
EV101WXM-N81 huwa modulu LCD ta '10 .1 pulzier bl-użu ta 'teknoloġija A-SI TFT-LCD. Huwa mgħammar bil-backlight WLED, inkluż LED Driver Backlight Drive, bla touch. Ir-riżoluzzjoni tal-wiri hija 1280 (RGB) × 800 (WXGA), il-proporzjon tal-aspett huwa 16:10 (wisa ': għoli), u l-pixel huma rranġati fi strixxi vertikali RGB. Id-daqs taż-żona tal-wiri tiegħu huwa 216.96 × 135.6 (wisa '× għoli) mm, id-daqs viżwali huwa 219.4 × 138.0 (wisa' × għoli) mm, id-daqs estern huwa 233.2 × 152.9 (wisa '× għoli) × 10.4 (ħxuna) mm, prodott nett tal-prodott 505g 505g (Tip.). F'termini ta 'backlighting, dan il-prodott juża sors ta' dawl tad-dħul tal-ġenb WLED b'ħajja ta '50k sigħat, inkluż sewwieq LED. EV101WXM-N81 juża l-interface tas-sinjal LVDs (1 CH, 8-bit), total ta '20 pin, juża konnessjoni terminali, il-vultaġġ tal-iskrin tas-sewqan huwa 3.3V (tip.). Ir-rata ta 'aġġornament vertikali tipika tagħha FV hija 60Hz. Jopera f'temperatura ta '-20 ° C sa 70 ° C u jaħżen f'temperatura ta' -30 ° C sa 80 ° C. Ibbażat fuq il-backlight LED abjad tagħha, il-ħajja hija aktar minn 50,000 siegħa.
R-Star oriġina minn Shenzhen, iċ-Ċina, aħna manifattur professjonali tal-High-End Highlight LCD, nistgħu nipprovdu minn 10.1 sa 120 pulzier li jenfasizzaw il-moduli LCD TFT, inkluż LCD semi-outdoor, skrin tal-qofol sħiħ fil-beraħ, ultrathin Highlight LCD, splicing ta 'barra, splicing ta' barra Jenfasizza l-LCD, il-qofol industrijali TFT-LCD, LCD trasparenti u l-qafas tal-wiri, LCD b'żewġ naħat, LCD b'livell għoli b'żewġ naħat u pannell LCD ieħor high-end. Fil-qosor, Rising għandu aktar minn 5 snin ta 'esperjenza ta' teknoloġija ta 'backlight ta' luminożità għolja, 8 snin ta 'disinn kbir ta' modulu TFT, riċerka u żvilupp, kapaċità ta 'produzzjoni, 10 snin ta' katina ta 'provvista ta' materja prima ta 'kwalità għolja.
| brand | BOE | Model name | EV101WXM-N81 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800, WXGA, 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96×135.6(H×V)mm | Surface treatment | / |
| Visual size | 233.2×152.9×10.4(H×V×D) mm | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 233.2×152.9×10.4(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
L-istess mudell ta 'daqs u parametri huma kif ġej
| brand | BOE | Model name | EV101WUM-N20 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1200, WUXGA, 224PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.806×135.504mm(H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 229.45×149.22(H×V)mm |
| Viewing Angle | 80/80/80/80(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 45 pins | ||
| work environment | Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | AT101WSM-N11-58P0 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×600, WSVGA, 117PPI | Pixel configuration | RGB vertical bar |
| Display Area | 222.72×125.28mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 226×128.6(H×V)mm | Contrast Ratio | 500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 235×144.9×5.44mm(H×V×D) |
| Viewing Angle | 80/80/60/70(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) , 60 pins , FPC | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | EV101WXM-N82 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800 [WXGA] 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96 × 135.6 mm (H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 228.6 ×149.2×6 mm (H×V×D) |
| Viewing Angle | 85/85/85/85(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 40 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
