Mudell Nru.: TDA150-005V01
TDA150-005V01 A-SI TFT-LCD 15-il pulzier Modulu tal-kristall likwidu, il-karatteristiċi tipiċi huma backlight LED abjad, inkluż sewwieq LED, wiċċ matte. It-temperatura operattiva tagħha hija -20 ~ 70 ° C, u t-temperatura tal-ħażna tagħha hija -30 ~ 80 ° C. Ir-riżoluzzjoni tal-wiri hija 1600 (RGB) × 1200 (UXGA), u l-pixel huma rranġati fi strixxi vertikali RGB. Id-daqs taż-żona tal-wiri tiegħu huwa 304.8 × 228.6 (w × h) mm, u d-dimensjoni esterna hija 317.4 (w) × 242 (h) mm.
Huwa sors ta 'dawl tat-tip tat-tarf b'ħajja ta' 30k siegħa, inklużi sewwieqa LED. TDA150-005V01 jadotta l-interface tas-sinjal LVDS (2 CH, 8-bit), total ta '40 pin, li huma konnessi minn terminali, u l-vultaġġ tas-sewqan huwa 3.3V (tip.).
Q ： Min aħna?
A ： R-Star oriġinat minn Shenzhen, iċ-Ċina, aħna manifattur professjonali tal-High-end High Highlight LCD, nistgħu nipprovdu minn 10.1 sa 120 pulzier li jenfasizzaw moduli TFT LCD, hemm aktar minn 100 impjegat, inklużi 20 inġiniera b'esperjenza. Il-kumpanija għaddiet ISO9001 / ISO14001 / CCC / CE / FCC / ROHS / UL u ċertifikazzjonijiet oħra, għandha pjattaforma ta 'R & D ta' livell għoli, u saret sieħba ODM / OEM ta 'bosta kumpaniji ta' klassi dinjija. Is-swieq tagħhom ikopru l-Asja, it-tramuntana, fit-tramuntana L-Amerika, l-Afrika, il-Lvant Nofsani, l-Ewropa, l-Amerika Ċentrali u t'Isfel u l-Oċeanja. Aħna nemmnu li jekk tagħtina ċ-ċans li naqdu, inkunu l-fornitur ta 'fiduċja tiegħek fiċ-Ċina.
Q ： Int Manifattur (Fabbrika)?
A ： Iva, aħna. Servizz OEM / ODM ukoll disponibbli hawn. Huwa l-pjaċir tagħna li nipprovdu l-aħjar soluzzjoni għalik.
Q ： Kif nistgħu niggarantixxu l-kwalità?
A ： Dejjem spezzjoni finali qabel il-ġarr.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
L-istess daqs u mudell huma kif ġej:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
