Mudell Nru.: LQ156M1LG21
L-LQ156M1LG21 għandu riżoluzzjoni tal-wiri tal-1920 (RGB) × 1080 (FHD), proporzjon tal-aspett ta '16: 9 (wisa ': għoli), u l-pixel huma rranġati fi strixxi vertikali RGB.
Id-daqs taż-żona tal-wiri ta 'LQ156M1LG21 huwa 344.16 × 193.59 (w × h) mm, id-daqs viżibbli huwa 349.0 × 198.4 (w × h) mm, id-daqs estern huwa 370 × 217 (w × h) × 9.8 (d) mm, Trattament tal-wiċċ Finitura matta, kisi iebes (3h), piż nett 950g (max.)
F'termini ta 'backlight, jintuża sors ta' dawl tat-tarf li jarmi d-dawl, u l-ħajja tas-servizz tas-sors tad-dawl hija 50k siegħa. It-temperatura operattiva tal-LQ156M1LG21 hija 0 ~ 70 ° C, u t-temperatura tal-ħażna hija -30 ~ 70 ° C.
| brand | Sharp | Model name | LQ156M1LG21 |
| size | 15.6inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD | Pixel configuration | RGB vertical bar |
| Display Area | 344.16×193.59(H×V)mm | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 349.0×198.4(H×V)mm | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 370×217×9.8(H*V*D) mm |
| Viewing Angle | 80/80/80/65 (Typ.)(CR≥10) | work environment | Storage temperature: 0 to 70 °C Operation Temperature: -30 to 70 °C |
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
